Spectrophotometers
Benchtop, portable and multi-angle spectrophotometers for precise color measurement, ΔE differences and reflectance analysis in the CIE L*a*b* space. Solutions for industry and laboratories.
Products in this category
KS-520 Spectrocolorimeter
A portable D/8 spectrocolorimeter with simultaneous SCI/SCE and a Φ40 mm sphere — with 12 apertures, camera preview and a full set of colour indices in a compact, handy body.
- D/8 geometry with simultaneous SCI/SCE measurement and a Φ40 mm integrating sphere
- 12 apertures (flat and nozzle) for flat, concave and hard-to-reach samples
- Full index set — WI, YI, MI, staining fastness, colour strength, opacity, Munsell
- Camera positioning, ΔE*ab 0.025 repeatability, weighs just 367 g
MS3012 Multi-Angle Spectrophotometer
A portable multi-angle spectrophotometer with 12 measurement angles for metallic, pearlescent and effect finishes — with Sparkle, Coarseness and Color Variation effect grading, compliant with DIN 6175 and SAE J1545.
- 12 measurement angles (7 sources, 2 receivers) for reliable metallic and pearlescent finish control
- Visual-effect grading — Sparkle Grade (SG), Diffuse Coarseness (DC) and Color Variation (CV)
- Compliant with automotive standards DIN 6175, ASTM D2244, ISO 7724 and SAE J1545
- ΔE*ab 0.02 repeatability, camera preview, lightweight approx. 1 kg body for on-site use
NS800 Spectrophotometer
Portable 45°/0° spectrophotometer for objective colour and ΔE measurement — ΔE*ab 0.04 repeatability, full reflectance curve and colour control at every production stage.
- 45°/0° ring-illumination geometry — measures the way the human eye sees, compliant with CIE / ISO / ASTM / DIN
- ΔE*ab 0.04 repeatability and ΔE*ab ≤ 0.2 inter-instrument agreement
- Full 400–700 nm reflectance curve and every ΔE formula (ab, uv, 94, cmc, 00)
- 3.5" touchscreen, 1,000 standards / 10,000 sample memory, USB and RS-232
NS810 Sphere Spectrophotometer
Portable d/8° sphere spectrophotometer with SCI measurement — Φ58 mm integrating sphere, ΔE*ab 0.04 repeatability and a full reflectance curve for colour control in the field or on the line.
- d/8° sphere geometry with a Φ58 mm integrating sphere, SCI measurement regardless of sample gloss
- ΔE*ab 0.04 repeatability and ΔE*ab ≤ 0.2 inter-instrument agreement
- Full 400–700 nm reflectance curve and the complete set of colour-difference formulas
- 3.5" touchscreen, 1,000 standards / 15,000 sample memory, USB and RS-232
PS230 Spectrocolorimeter
A compact entry-level D/8 (SCI mode) spectrocolorimeter with a Φ40 mm sphere — with MAV/SAV/SSAV apertures, camera positioning and ΔE*ab 0.02 repeatability for fast colour control.
- D/8 geometry (SCI mode) with a Φ40 mm integrating sphere — spectral measurement at an entry price
- Three aperture ranges — MAV Φ8/10 mm, SAV Φ4/5 mm and SSAV 1 × 3 mm
- ΔE*ab 0.02 repeatability and ΔE*ab 0.2 inter-instrument agreement (12 BCRA tiles)
- Very compact body (94 × 68 × 188 mm, 410 g) with camera-based positioning
PS430 Spectrocolorimeter
A portable D/8 spectrocolorimeter with simultaneous SCI/SCE and a Φ40 mm sphere — with 12 apertures, camera positioning and ΔE*ab 0.02 repeatability in a compact body.
- D/8 geometry with simultaneous SCI/SCE measurement and a Φ40 mm integrating sphere
- ΔE*ab 0.02 repeatability and ΔE*ab 0.2 inter-instrument agreement (12 BCRA tiles)
- 12 apertures (flat and nozzle) plus camera-based measurement positioning
- Li-ion battery for up to 8,000 measurements, weighs just 367 g for field use
TS-26C Portable Spectrophotometer (45°/0°)
A portable 45°/0° spectrophotometer with seven apertures, fluorescent-sample and retro-reflective material measurement — with a 3.5" touchscreen, Bluetooth 5.0 and ΔE*ab 0.018 repeatability.
- 45°/0° geometry that faithfully mirrors visual assessment of matte and textured surfaces
- Seven measuring apertures — from 12 mm to 1 × 3 mm — for large and very small samples
- Fluorescent-sample and retro-reflective material measurement (road signs, films per GB/T 18833)
- ΔE*ab 0.018 repeatability, 3.5" touchscreen, Bluetooth 5.0 and app control
TS4020 Liquid Spectrophotometer
A benchtop transmission spectrophotometer for the colour and transmittance of liquids — with a full set of industrial indices (APHA/Pt-Co, Gardner, Saybolt, ASTM D1500, pharmacopoeia, EBC, ICUMSA), a Φ40 mm sphere and a 7" touchscreen.
- Dedicated colour and transmittance measurement of liquids in D/0 transmission geometry
- Full set of industrial scales — APHA/Hazen/Pt-Co, Gardner, Saybolt, ASTM D1500, iodine, Klett
- Industry scales — pharmacopoeia (CN/EU/US), EBC (beer), ICUMSA (sugar), turbidity
- High ΔE*ab 0.01 repeatability, 360–780 nm range, 7" touchscreen
TS7700 Benchtop Spectrophotometer
An advanced d/8° sphere spectrophotometer with simultaneous SCI/SCE measurement, a 1,000-line grating monochromator and ΔE*ab 0.02 repeatability — including fluorescent samples.
- Dual optical path — simultaneous SCI and SCE measurement, including fluorescent samples
- 1,000-line diffraction-grating monochromator with a dual 40-element silicon photodiode
- ΔE*ab 0.02 repeatability and ΔE*ab ≤ 0.15 inter-instrument agreement
- Interchangeable Φ8/10 mm (MAV) and Φ4/5 mm (SAV) apertures, plus 8° gloss measurement
TS8560 Benchtop Spectrophotometer (LED + xenon)
A flagship benchtop spectrophotometer with dual LED + xenon light sources, reflectance and transmittance (haze) measurement and a Φ154 mm sphere — with a rotatable 7" screen, 32 GB storage and automatic temperature/humidity compensation.
- Dual light source LED + xenon lamp — better identification of fluorescent samples
- Reflectance (SCI/SCE) and transmittance plus haze (per ASTM D1003) in a single instrument
- Four aperture ranges (XLAV/LAV/MAV/SAV) and a transmission chamber for samples up to 54 mm thick
- Rotatable 7" touchscreen, 32 GB storage, camera positioning, temperature/humidity compensation
YS3010 Spectrophotometer
The entry-level sphere spectrophotometer in the YS series — d/8° geometry, simultaneous SCI/SCE measurement and simple operation for routine colour control.
- d/8° sphere geometry (Φ48 mm) with simultaneous SCI and SCE measurement
- Simple single-aperture measurement — the most accessible configuration in the YS series
- ΔE* ≤ 0.06 repeatability — enough for routine quality control
- USB connectivity, 2,000 standards / 20,000 sample memory, built-in sample-preview camera
YS3020 Spectrophotometer
The YS-series sphere spectrophotometer with the widest aperture choice (8/4/1×3 mm) — simultaneous SCI/SCE measurement and 9 illuminants for samples of any size.
- d/8° sphere geometry (Φ48 mm) with simultaneous SCI and SCE measurement
- Adjustable measuring aperture Φ8/4/1×3 mm — the widest range in the YS series
- ΔE* ≤ 0.05 repeatability and ΔE* ≤ 0.2 inter-instrument agreement
- USB connectivity, 2,000 standards / 20,000 sample memory, built-in sample-preview camera
YS3060 Spectrophotometer
The flagship sphere spectrophotometer in the YS series — simultaneous SCI/SCE measurement, 18 illuminants, ΔE* ≤ 0.03 repeatability and a built-in sample-preview camera.
- d/8° sphere geometry (Φ48 mm) with simultaneous SCI and SCE measurement
- Dual interchangeable measuring apertures plus a UV lamp for optical-brightener detection
- ΔE* ≤ 0.03 repeatability and ΔE* ≤ 0.15 inter-instrument agreement — the best in the YS series
- USB and Bluetooth, 2,000 standards / 20,000 sample memory, built-in sample-preview camera
YS6060 Benchtop Spectrophotometer
A laboratory benchtop spectrophotometer with d/8° geometry and simultaneous SCI/SCE — measuring both reflectance and transmittance (haze), with a Φ154 mm sphere, 360–780 nm range and a 7" touchscreen.
- Reflectance AND transmittance (haze per ASTM D1003) in a single benchtop instrument
- d/8° geometry with simultaneous SCI/SCE, Φ154 mm integrating sphere, 360–780 nm range
- ΔE*ab 0.01 repeatability and ΔE*ab 0.12 inter-instrument agreement (12 BCRA tiles)
- Rich industrial index set — WI, YI, Gardner, APHA/Pt-Co, ASTM D1500, pharmacopoeia, EBC, ICUMSA
